Product Overview
- High-speed color digital cameras for optical mark read (OMR) and color image scanning in a single pass
- 750 sheet autofeed; 750 sheet output tray (main); 250 sheet select stacker
- Up to 15,000 sheets per hour
- PC Controller included
- Scans up to 16 mark levels, 256 grayscale levels, 16 million colors
- Captures pencil or ink OMR marks, barcodes, handprint, images (complete form or image snippets such as comment clips, handwritten responses, student pictures, thumbprints, and much more)
- Open feed path to reduce dust buildup
| Physical | Document Transport: 55″ H x 48″ W x 29″ D (139.7 cm H x 121.3 cm W x 73.7 cm D) Weight: Approximately 485 lbs. (219 kg) |
| Environmental | Operating Temperature: 68°–80°F (15.6°C – 26.7°C) Humidity: 40%–60%, noncondensating |
| Power | Standard: 47–63 Hz ±5%, 100-240 VAC ±10%. Requires 15 amp dedicated circuit, single phase |
| Communication | PC controller supplied with scanner |
| Operations | Maximum Speed: 15,000 8½” x 11″ (216 mm x 280 mm) sheets per hour Read Head: OMR: Pencil (Infrared) and Ink (Red); Image: 240 dpi, 16 million colors Hopper/Stacker Capacities: Input Hopper: 750 sheets; Output Stacker: 750-sheet main and one 250-sheet select stacker Controls: Computer keyboard is primary control, in addition to a convenient Ready button on the control panel Status Indicators: Paper sensor status lights appear on the control panel Forms: 3¼” x 7″ to 9″ x 12″ (82.5 mm x 177.8 mm to 229 mm x 305 mm); uses standard Scantron Mark Reflex® forms |
| Components | Read Head: mark discriminating, self-calibrating read head, two-sided reflective read Document Transport: Automatic feed, active sheet deskew, two output stackers Options: Transport printer, Bar code reader |
The iNSIGHT 1500c includes a Scantron-certified PC controller as an integral component. Although based on a standard PC framework, this controller includes proprietary software and/or hardware that have been installed, tested, and certified by Scantron to work with high-speed precision production scanners. The certified controller is considered to be a proprietary component of the scanner. The controller is warranted and supported as a scanner component. Contact a Scantron representative for further details.
